Scene.js Intro

This is a JavaScript library. It can be used to display one or multiple instances of scene(s).

Scene refers to a stage or scene used in theater and film (See: Wikipedia).

Such scene consists of characters, props, cameras, lights etc., their positions and their animations.

This library is used to display dynamic or static layout of a scene with such props and characters.

The style and functionalities of this doc website and library work on both desktop and mobile.

However, there's an issue affecting Webkit browsers (see Known Issues).

Movie Prop Properties​

Every prop can also contain following properties:

  • Type
  • Style
  • Is enabled
  • Color
  • Name
  • Note
  • Scripts
  • Steps (a list of step number with instructions)
  • Multiple images with titles (e.g., storyboard/director's viewfinder)

Disclaimer

Even though this landing page is built using React and Docusaurus, the library doesn't use React.

In fact, the library itself doesn't use any external js/css libraries and can be used both in vanilla html/js with script tag and ESM environments.

Libraries used for development and docs​

The library is written in TypeScript.

  • Webpack is used to bundle its TypeScript files to a single js file.
  • Bootstrap icon font is used for button icons and props.
  • I don't own any images used in this docs page.
DOM Manipulation

Even though some part of this library uses SVG tags (including <g>, <path>).

DOM manipulation were mainly used to layer them, apply different attributes to different layers of elements and attach event listeners.

Apart from the SVG part, the library also contains a large amount of DOM manipulation (see User - Interactions).

Inline CSS in docs

Some examples used in this docs website contain inline css code since this is easier to demonstrate with compared to css class.

Getting Started

To import this library, all you need to do is include one script tag in your header:

(You don't need to include any extra libraries or css files)

Do note that if you import it using script tag, you will need to prefix your calls with SceneJS (e.g., new SceneJS.Scene(id, config) (see below))

<script type="text/javascript" src="https://scene.muddy.ca/scene.js"></script>

Support for multiple instances​

You can safely create multiple instances of scenes in a single page.

Mount / Unmount​

You can expect a scene to safely unmount itself and cancel all its timeouts when the scene cannot find its root element. (e.g., you removed its root container)

You don't need to handle any of the above-mentioned features on your side.

If you need to display the scene again after it's been unmounted. You can use the same scene instance and call scene.display() again.

Scene Instances

By design, a scene object can only be attached to 1 container id.

Even though you can change its container or mount / unmount it, you cannot render the same scene instance in multiple containers.

To render multiple instances of scenes, either clone your config or create new ones and pass them to a new scene object.

Create a scene

The scene will be rendered in your container. It will take up all your container's space (see below).

You don't need to set any size related configs in the library.

Note that you can use a css class for your container.

For instance, you can have a scene with mobile width by setting its container width:

Set up scene configs​

Essentially, there are 3 types of objects you need to create:

  1. Global Config: contains all global settings of your scene instance
  2. Prop Config: contains all prop related config of any prop
  3. Animation Config: contains all animation (position, scale, rotation etc.) config of your prop (frame based)

There are 2 ways to create any scene, its props and prop animation configs:

  1. Use their related generators: GlobalConfigGenerator, PropConfigGenerator and PositionConfigGenerator
  2. Create their json and pass the config to the scene
Generator chaining and callbacks

You can chain methods in all generators.

For instance:

new GlobalConfigGenerator()
    .withFrameSpeed()
    .showPropList(false)
    .showTimeline(false)
    .withProps().getConfig()

You can also use callbacks in GlobalConfigGenerator and PropConfigGenerator to configure a prop or position:

For instance:

new GlobalConfigGenerator()
    .addProp((propGenerator) => {
    propGenerator.type('TABLE').addPosition((positionGenerator) => {
       positionGenerator.x(50).y(50).transitionTimingFunction('ease-in')
    }, 1).addPosition((positionGenerator) => {
       positionGenerator.x(100).y(100).scale(2)
    }, 2).getConfig()

Create a demo scene​

Please see sidebar Global Config and Prop Config for more information.

Below is a simple example to create a demo scene.

I've included all 3 ways to create it:

Note that I chose to include the entire index.html file in case any part is confusing. Any other example used in this docs website will not contain the html file.

Code Snippet
index.html
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<title>Scene.js demo</title>
<script type="text/javascript" src="https://scene.muddy.ca/scene.js"></script>
<body>

<div id="some-container-id" style="width: 800px; height: 600px"></div>

<script defer>
    const globalConfigGenerator = new SceneJS.GlobalConfigGenerator()
    .defaultOpenToolbar(false)
    .autoPlay(true)
    .addProp((generator) => {
    generator.type('TABLE').addPosition((positionGenerator) => {
        positionGenerator.x(50).y(50)
    }, 1).addPosition((positionGenerator) => {
        positionGenerator.x(90).y(90)
    }, 2)
})
    .addProp((generator) => {
    generator.type('CAMERA').addPosition((positionGenerator) => {
        positionGenerator.x(200).y(200)
    }, 1).addPosition((positionGenerator) => {
        positionGenerator.x(50).y(50)
    }, 2)
})
    const scene = new SceneJS.Scene('some-container-id', globalConfigGenerator.getConfig())
    scene.display();
</script>

</body>
</html>
CHECK ANY SCENE'S CONFIG WITH EXPORT

If the toolbar of a scene is enabled (it's enabled by default), you can export the entire config of that scene by clicking the export button in the bottom left toolbar.

The config will be copied to your clipboard.

You can pass the config to Scene constructor to create an identical scene.
